General technical specifications
Supplement and corrections to section 8.4.1 of the operating instructions
Teaming is not possible in connection with Windows 10.
Mechanical ambient conditions
Vibration
Operation
1, 2
Storage/transport
Resistance to shock
Operation
1, 2
Storage/transport
Special features
Quality assurance in accordance with
Mechanical interference must be safely excluded during the burning operation.
1
Restrictions when HDDs are mounted in removable drive bays: Shocks up to 5G are permitted only for operation with
2
SATA hard disk drives. Otherwise, mechanical stress must be safely excluded.
Correction of the Quick Install Guide and the following sections of the operating instructions:
Sec. 6.1 Retrofitting instructions
Sec. 8.4.1 General technical specifications
Note
The permissible lower operating temperature is dependent on the device configuration!
Lower operating temperature
Component
SATA HDD
SATA SSD
SAS HDD
DVD burner drive
SIMATIC IPC647D
A5E38487417-AD, 09/2017
Tested in accordance with IEC 60068-2-6, 10 cycles
10 Hz ... 58 Hz: 0.0375 mm, 58 Hz to 500 Hz: 4.9 m/s
5 Hz ... 9 Hz: 3.5 mm, 9 Hz to 500 Hz: 9.8 m/s
Tested in accordance with IEC 60068-2-27, IEC 60068-2-29
Half-sine: 50 m/s2, 30 ms, 100 shocks per axis
Half-sine: 250 m/s2, 6 ms, 1000 shocks per axis
ISO 9001
Lower operating temperature
0 °C
0 °C
5 °C
5 °C
2
2
