HAWA Frontslide 140 matic Symmetric 2 Planungs- Und Montageanleitung Seite 9

Hawa Frontslide 60 matic Symmetric 2 100 matic Symmetric 2 140 matic Symmetric 2
2 Product information
Intended use
The Hawa Frontslide 60 matic Symmetric 2, Hawa awa Frontslide 100 matic Symmetric 2 and
Hawa Frontslide 140 matic Symmetric 2 serves exclusively as a privacy screen and sun protection.
Intended place of use
External area with a rural inland climate, no particularly high pollution burden and at least 20 km (12.4 mi) away from the sea.
Technical data
Hawa Frontslide 60 matic Symmetric 2
Max. weight per sliding shutter
Max. area per sliding shutter
Min. sliding shutter width
Max. sliding shutter height
Sliding shutter thickness
Max. installation width
Hawa Frontslide 140 matic Symmetric 2
Max. weight per sliding shutter
Max. area per sliding shutter
Min. sliding shutter width
Max. sliding shutter height
Sliding shutter thickness
Max. installation width
Certificates are available for downloading at www.hawa.com
Article number
Articles are identified by a 5-digit number.
General notes
Installation is illustrated using a Hawa Frontslide 60 matic Symmetric 2, as an example.
Deviating work steps for Hawa Frontslide 100 matic Symmetric 2 and Hawa Frontslide 140 matic Symmetric 2 are indicated accord-
ingly. The document "Safety notes" (22991) and the "Installation and commissioning instructions" (24675) for the
Hawa Motronic 60, Hawa Motronic 100 and Hawa Motronic 140 are integral components of these planning and installation
instructions.
Once the Hawa Frontslide 60 matic Symmetric 2, Hawa Frontslide 100 matic Symmetric 2 and Hawa Frontslide 140 matic Sym-
metric 2 have been installed, the Hawa Motronic 60, Hawa Motronic 100 or Hawa Motronic 140 drive unit must be installed and
taken into operation by a qualified person.
The Hawa Motronic 60, Hawa Motronic 100 or Hawa Motronic 140 drive unit detects objects, stops and reverses (2x).
The operating instructions and the document titled "Safety notes" (22991) must be handed over to the end user of powered systems.
The pamphlet "Using shading systems in snow and ice" (24102) is available for downloading from our homepage.
Metric measurements apply – those in inches are for information only.
Retain the instructions. Replacements available from www.hawa.com.
Risk and residual risk
The hardware does not pose a risk or residual risk.
Disposal
Materials, accessories and packaging should be recycled in an environmentally friendly manner.
60 kg (132 lbs.)
6.24 m² (67.1668 ft²)
21
550 mm (1'9 ")
---- -
32
3200 mm (10'6")
1 25
28-45 mm (1 "-1 ")
---- -
- -
32
8
9
7500 mm (24'7 ")
---- -
32
100 kg (220 lbs.)
6.24 m² (67.1668 ft²)
17
750 mm (2'5 ")
---- -
32
3200 mm (10'6")
1
28-60 mm (1 "-2 ") 3
- -
- -
8
8
9
7500 mm (24'7 ")
---- -
32
Hawa Frontslide 100 matic Symmetric 2
Max. weight per sliding shutter
Max. area per sliding shutter
Min. sliding shutter width
Max. sliding shutter height
Sliding shutter thickness
Max. installation width
80 kg (176 lbs.)
6.24 m² (67.1668 ft²)
600 mm (1'11 ")
5
- -
8
3200 mm (10'6")
28-50 mm (1 "-1 ") 1 31
- - ---- -
8 32
9
7500 mm (24'7 ")
---- -
32
9/36
