Product Information - HAWA Frontslide 100 A Telescopic 4 Planungs- Und Montageanleitung

Hawa Frontslide 60 A Telescopic 4 100 A Telescopic 4

2 Product information

Intended use
The Hawa Frontslide 60 A Telescopic 4 and Hawa Frontslide 100 A Telescopic 4 serves exclusively as a privacy screen and sun pro-
tection.
Intended place of use
External area with a rural inland climate, no particularly high pollution burden and at least 20 km (12.4 mi) away from the sea.
Technical data
Hawa Frontslide 60 A Telescopic 4
Max. weight per sliding shutter
Min. sliding shutter width
Max. sliding shutter width
Max. sliding shutter height
Sliding shutter thickness
Certificates are available for downloading at www.hawa.com.
Article number
Articles are identified by a 5-digit number.
General notes
Installation is illustrated using a Hawa Frontslide 60 A Telescopic 4 as an example. Deviating work steps for
Hawa Frontslide 100 A Telescopic 4 are indicated accordingly.
The document "Safety Notes" (22991) is an integral component of these planning and installation instructions. Carry out a function
check when installation is complete. Hand over the instructions and the "Safety Notes" document (22991) to the end user after the
function check.
Metric measurements apply – those in inches are for information only.
Retain the instructions. Replacements available from www.hawa.com.
Risk and residual risk
The hardware does not pose a risk or residual risk.
Disposal
Materials, accessories and packaging should be recycled in an environmentally friendly manner.
60 kg (132 lbs.)
21
550 mm (1'9 ")
---- -
32
1
1200 mm (1'11 ")
- -
4
3200 mm (10'6")
19
1
28–40 mm (1 "-1 ")
- - ---- -
8 32
Hawa Frontslide 100 A Telescopic 4
Max. weight per sliding shutter
Min. sliding shutter width
Max. sliding shutter width
Max. sliding shutter height
Sliding shutter thickness
100 kg (220 lbs.)
5
600 mm (1'11 ")
- -
8
1
1200 mm (1'11 ")
- -
4
3200 mm (10'6")
1
19
28–40 mm (1 "- 1 ")
- -
---- -
8
32
7/36
