2 Product information

Intended use
The Hawa Frontslide 60 A / Hawa Frontslide 100 A / Hawa Frontslide 140 A serves exclusively as a privacy screen and sun
protection.
Intended place of use
External area with a rural inland climate, no particularly high pollution burden and at least 20 km (12.4 mi) away from the sea.
Technical data
Hawa Frontslide 60 A
Max. weight per sliding shutter
Min. sliding shutter width
Max. sliding shutter height
Sliding shutter thickness
Hawa Frontslide 140 A
Max. weight per sliding shutter
Min. sliding shutter width
Max. sliding shutter height
Sliding shutter thickness
Certificates are available for downloading at www.hawa.com
Article number
Articles are identified by a 5-digit number.
General notes
Installation is illustrated using a Hawa Frontslide 60 A as an example. Deviating work steps for Hawa Frontslide 100 A and
Hawa Frontslide 140 A are indicated accordingly.
The document "Safety Notes" (22991) is an integral component of these planning and installation instructions. Carry out a function
check when installation is complete. Hand over the instructions and the "Safety Notes" document (22991) to the end user after the
function check.
Metric measurements apply – those in inches are for information only.
Retain the instructions. Replacements available from www.hawa.com.
Risk and residual risk
The hardware does not pose a risk or residual risk.
Disposal
Materials, accessories and packaging should be recycled in an environmentally friendly manner.
Hawa Frontslide 100 A
60 kg (132 lbs.) Max. weight per sliding shutter
3
400 mm (1'3 ") Min. sliding shutter width
- -
4
3200 mm (10'6") Max. sliding shutter height
25
1
28–45 mm (1 "-1 ") Sliding shutter thickness
- - ---- -
32
8
140 kg (308 lbs.)
9
700 mm (2'3 ")
---- -
16
3200 mm (10'6")
1 3
28–60 mm (1 "-2 ")
- - - -
8 8
100 kg (220 lbs.)
11
500 mm (1'7 ")
---- -
16
3200 mm (10'6")
1 31
28–50 mm (1 "-1 ")
- - ---- -
8 32
