EN INSTALLATION AND INSTRUCTION MANUAL
Please read the manual carefully before you start installing and using it and
keep the manual for future reference. The products are meant only to be used as
a sauna heater and for heating the sauna.
Technical data
COMBI 9kW, 10,5kW
1. PACKAGE CONTETS
1. Stove
2. Fixing screws
3. Installation and instruction manual
The sauna controller is not included in the
heaters price. The external controller that is
connected with the heater must be designed for
sauna control purpose.
The control unit needs to fullfill referring local
and European standards for electri-cal devices
and sauna heating appliances. The control unit
must be equipped with a separate temperature
sensor and safety device (over heating
protection) in accordance with standard EN
60335-2-53.
Suitable control unit for this heater is Narvi
Dual ND105.
Heater
Capacity
model
9 kW
COMBI
10,5 kW
Table 1. Installation information for heater
12
Width (mm)
Depth (mm)
450
450
Sauna room
on the
Volume
Height
sides
(m
)
min. (mm)
A **)
3
8–12
1900
9–15
1900
Height (mm)
930
2. PRIOR TO INSTALLATION
Perform the following checks:
– The stove is the right size (kW) for the size of
the sauna (m³).
– Table 1 shows the sauna volumes for different
stove types.
– For every 1 m² of uninsulated brick, tile or glass
wall surface in the sauna, increase the sauna
volume by 1.5 m³ when choosing the required
stove wattage from Table 1.
– The sauna volumes indicated in Table 1 are
both maximum and minimum values.
– Table 1 indicates both the minimum height of
the sauna and the minimum safety distances
for the stove.
ALWAYS CHECK THE SAUNA BEFORE
SWITCHING ON THE STOVE.
Minimal safety clearances to the heater
at the
at the
front
front
B **)
C **)
mm
mm
mm
50
50
50
50
50
50
**) See figure 1
Weight
(kg, without stones)
58
to the
400 V
ceiling
to the floor
D **)
E **) mm
mm
970
30
970
30
*) Connected with rubber cable, type H07RN-F
or corresponding cable
Quantity of stones
Ø 5–10 cm (kg)
50
Connection *)
Fuses
3N~
A
mm
2
5x2,5
3x16
5x2,5
3x16
