Important informationen
Important information
The distybase uno exant is a DECT base station that can be used for
operating the distybox 300/5000. The distybase uno exant can be used
on an analogue telephone connection with DTMF dialling. In combination
with a registered distybox, cordless connection of analogue terminals to
the telephone network is possible within the radio range. This "cordless
extension cable" removes the need for time-consuming cabling work for
your analogue telephones, fax machines, answerphones, door intercoms
and modem.
The distybase uno exant has an SMA aerial connection for an external
aerial. This is used to connect a DECT aerial, which can extend the range
of the distybase uno exant. Depending on the aerials used and the
environmental conditions, it is possible to bridge up to 10 km. The
distybox 300 can be used at a distance of up to 50 m within buildings and
300 m out of doors. By using a distybox 5000 with an external aerial, a
distance of up to 9,000 m may be covered, depending on the type of
aerial used and general environmental conditions.
NOTE
The distybase uno exant is set for operation on an analogue telephone
connection conforming to the TBR 21 standard with a long flash time.
Connections and operating elements
Connections and operating elements
2
220/230V
50 Hz
1
Power supply
2
AC adapter
NOTE
Only use the supplied AC adapter with the coloured RJ-11 plug.
Ensure that the AC adapter is unplugged before opening the
housing.
3
LED
4
Register button
5
Connection for telephone line.
The RJ-11 jack is assigned to the two centre connections
(pins 3 and 4).
6
Aerial connection
SMA aerial socket for connecting an external aerial
Using a high-quality aerial cable and as short a cable as possible minimises
NOTE
performance losses and optimises the coverage.
1
2 m
5
3
6
4
3
