Telephoning
• When you lift the telephone handset on your registered distybox
300/5000, you will hear the dialling tone for your telephone line. You
are making an external call. The connection is established by entering
the appropriate phone number.
• Incoming calls to your telephone line are signalled on all registered
distybox 300/5000 units at the same time.
• Please observe the operating instructions for your distybox 300/5000.
Annex
Technical data / features
Standard:
DECT (Digital Enhanced Cordless
Telecommunications), GAP-compatible
Frequency range:
1,880 MHz to 1,900 MHz
Transmission output:
10 mW on average
Aerial socket:
SMA socket for an external aerial
via coaxial cable
Voice transmission:
32 kbit/s ADPCM
Fax mode:
Group 3, V.29 at a maximum of 9,600 bit/s
Modem mode:
Maximum 9,600 bit/s
Dialling procedures:
DTMF
Number of cordless
handsets:
6 distybox 300/5000
Conformity:
EN60950:2000, TBR 21, ETS 300 444,
ETS 300 659-1/300 778-1, EN301 406;
TBR10
Public exchange connection: Country support conforming to TBR 21
Austria, Belgium, Denmark, Finland, France,
Germany, Great Britain, Greece, Iceland,
Ireland, Italy, Luxemburg, the Netherlands,
Norway, Poland, Portugal, Spain, Sweden,
Switzerland
CLIP:
Protocol conforms to ETSI standard, type 1
(only when used with distybox 300/5000)
Flash time:
long (200 ms)
Operating temperature:
+10°C to +40°C
Relative humidity:
20% to 75%
Permissible
storage temperature:
-10°C to +60°C
Display unit:
LED for exchange access / registration
Operating unit:
Button for registration
Dimensions:
120 x 100 x 38 mm (W x H x D)
Weight:
120 g
Mounting location:
Wall mounting indoors
Power supply:
6 V AC/ 8 V DC (+/- 15%) (60 mA zero
signal current, maximum 180 mA)
Scope of delivery:
AC adapter 230 V AC, 50 Hz
Connection cable for telephone socket
