Sungrow SG2.0RS-S Schnellstartanleitung Seite 36

Ethernet
1
RJ45 plug
Protection cap
3
6
9
COM2
Label
RS485 (A1, B1)
Meter (B2, A2)
DRM (R, C)
RSD (RSD-1, RSD-2)
TIA/EIA 568A TIA/EIA 568B
4
7
10
Click
Description
Reserved
Smart energy meter interface
For external Demand Response Enabling Device ("AU"/"NZ")
Reserved
35
2
5
8
Click
RS485 Meter DRM
A1 R
A2
B1 C
B2
(Hand-tight)
RSD
RSD-1
RSD-2
