4x LED1 yellow
LED green AUX
auxiliary voltage
inputs
3
4
5
2
1
socket M12
sensor supply L+
sensor supply L-
data input
not connected
Addressing
Assign a free address between 1 and 31. At the factory the address is
set to 0.
Addressing with the adressing unit AC1144
If it is used with the FC-E lower part without addressing socket the
module must first be addressed via the addressing unit AC1144 and
then mounted onto the lower part.
6
LED3 infrared reciever
outputs
pin
1
3
2+4
5
LED2 red FAULT
fixture infrared
adapter
LED green PWR
sensor supply o.k
4 sockets M12
3
4
5
2
1
socket M12
switching output +
external voltage -
not connected
pin
4
3
1,2,5
