Installation Guide
1 . Installation Steps
EN
1 . Installation must be done by an authorised
electrician .
2 . The room thermostat should be installed at approx .
1 .5 m above floor and where the effects of sunlight,
draught or other heat sources (eg . TV's) are avoided,
see fig . 1 .
3 . To access wiring terminals loosen screws, remove
front cover and carefully pull off thermostat dial,
see fig 2 .
4 . After mounting and wiring replace dial . Front cover
must be angled at the top to accept retaining tabs
and carefully lowered into position before tighten-
ing screws, see fig 3 .
2 . Dimensions and Wiring
See fig . 4 for dimensions and fig . 5 for wiring diagram .
4
RET1001M Room Thermostat
VISUM14F Danfoss Heating Solutions
