Installation Guide

1 . Installation Steps

EN
User Guide can be downloaded from: heating.danfoss.com.
1 . Installation must be done by an authorised
electrician .
2 . The room thermostat should be installed at approx .
1 .5 m above floor and where the effects of sunlight,
draught or other heat sources (eg . TV's) are avoided,
see fig . 1 .
3 . First of all, carefully remove the cover, see fig . 2 .
4 . Connect the wire before mounting the back plate to
the wall box using the enclosed screws . Then mount
the cover to the back plate, see fig 3 .
2 . Dimensions and Wiring
Dimensions, see fig . 4 . Wiring diagram, see fig . 5
