Installation Guide

1 . Installation Steps

EN
User Guide can be downloaded from: heating.danfoss.com.
1 . Installation must be done by an authorised
electrician .
2 . The room thermostat should be installed at approx .
1 .5 m above floor and where the effects of sunlight,
draught or other heat sources (eg . TV's) are avoided,
see fig . 1 .
3 . First loosen lower retaining screw and carefully
remove back plate, see fig . 2 .
4 . Mount back plate direct to wall or on wall box and
wire according to application, see figs 3 & 5 accord-
ing to application .
5 . Insert 2x AA Alkaline batteries to front part taking
care to insert correctly as indicated .
6 . Locate hooks at top of front part into top of back
plate and lower into position and tighten retaining
screw .
2 . Dimensions and Wiring
Dimensions, see fig . 4 . Wiring diagram, see fig . 5 .
