Installation Guide

1 . Installation Steps

EN
User Guide can be downloaded from: heating.danfoss.com.
1 . Installation must be done by an authorised
electrician .
2 . The room thermostat should be installed at approx .
1 .5 m above floor and where the effects of sunlight,
draught or other heat sources (eg . TV's) are avoided,
see fig . 1 .
3 . Decide location of RX1-S receiver, ensuring a
minimum space of 30cm from boiler housing . There
must be no large metal objects, such as boiler cases
or other large appliances, in line of sight between
the thermostat and the receiver as this will prevent
RF communication, see fig . 1 .
4 . Remove and mount RX1-S back plate direct to wall
or on wall box, and wire as required for application,
see fig . 2 .
5 . Locate hooks at top of RX1-S into top of back plate
and lower into position and tighten retaining screw .
Switch on mains power to start RF pairing .
6 . Loosen lower retaining screw of thermostat and
carefully remove back plate, see fig . 3 .
7 . Insert 2x AA Alkaline batteries to front part taking
care to insert correctly as indicated . Check RF con-
nection between Thermostat and RX1-S Receiver
before fixing in final position, see RF Pairing below .
