Maintenance
Backflushing
Do not backwash when using Steinbach Filter Balls. If the filter throughput decreases, we
recommend washing the filter balls by hand. If necessary, exchange the filter balls.
1. Switch the pump
3
2. Connect the backwash line (see section "Connecting the backwash line").
3. Press and hold down the valve lever
4. Set the valve lever to the "BACKWASH" position and release it.
5. Connect the pump's power plug to the power supply.
6. Backwash the system until clean water emerges from the backwash line (max. 2 minutes).
7. Switch the pump
3
8. Press and hold down the valve lever
9. Set the valve lever to the "RINSE" position and release it.
10. Connect the pump's power plug to the power supply.
11. Let the pump run for 20 to 30 seconds to remove any residue in the valve head.
12. Switch the pump
3
The backwashing is completed.
Exchanging the filter medium
The filter medium used (quartz filter sand or filter balls) is subject to wear, even under
optimum conditions and should be exchanged at regular intervals, depending on the
operating time and the amount of dirt that has accumulated.
1. Switch the pump
3
2. Close the shut-off valves or block the water flow to the pool's connecting hoses.
3. Screw in the drainage opening
4. Completely drain the water from the filter vessel
5. Screw the drainage opening into the filter vessel.
6. Undo the locking ring
purpose.
7. Put aside the locking ring and its screws.
8. Slowly turn the filter vessel on its head and remove the quartz filter sand or the filter balls.
9. Remove the screen
10. Thoroughly rinse the screen under flowing water.
11. Rinse the filter vessel with clean water.
12. Carry out the steps described in the "Preparing the filter vessel" section.
The filter medium is exchanged.
Replacing the timer battery
1. Make sure that the pump's power cable is disconnected from the power supply.
2. Undo the screws of the timer cover with a Phillips screwdriver PH1 and remove the cover.
3. Lightly push down on one edge of the battery to loosen it. Remove the battery.
4. Replace the battery (see section "Technical data").
5. Screw the cover back on.
The timer battery is exchanged.
Cleaning
Only clean the device with a standard bathroom cleaner, clear tap water and a lint-free cloth. Aggressive
cleaning agents can damage the device. Dry the product with a lint-free cloth.
off by pulling the power plug.
on the valve head
22
off by pulling the power plug.
on the valve head
22
off by pulling the power plug.
off by pulling the power plug.
so that it comes out of the base of the filter vessel
17
by turning the screw counter-clockwise. Use the Allen wrench
5
.
6
.
1
.
1
via the drainage opening.
2
.
2
for this
14
