Miganeo Speed Clean 7000 Bedienungsanleitung Seite 22

Package contents
Valve head
1
Filter vessel
2
Pump
3
Vessel seal
4
Locking ring
5
Screen
6
Centering device
7
Drainage screws set
8
Components
Drainage opening
17
Bleeder screw
18
Suction line
19
Optionally available accessories
Return line adapter INTEX Pools/
23
Speed Clean;
art. 040934
22
Base plate
9
Screw set for fastening the pump (2x)
10
Pressure hose "PUMP" (is supplied in the riser pipe of the
11
screen)
Hose clamp (2x)
12
Manometer
13
Allen wrench
14
Teflon tape
15
Filter balls
16
Operating instructions (no illustration)
Return line "RETURN"
20
Backflush line "WASTE"
21
Valve lever
22
Housing for UV disinfection system, item no. 040530
24
UV disinfection system, item no. 040511
25
