3. Press the TIMER button several times until the LED "24" is lit.
The 24-hour setting indicates continuous pump operation.
4. Press the ON/OFF button.
The pump is switched on and is controlled by the timer from that point onward.
Filtering time
The pool's water content should be circulated at least twice in a 24 h period. In case of heavier
frequency, the pool water should be circulated 3 to 5 times per day.
Before First Use
Check the following before start-up
- The device is out of the pool and the power cable is disconnected from the mains
- Feed and drain lines are correctly attached and the water level of the pool is at least 2.5 to 5 cm
(1-2") above the opening of the suction line
Mounting the pump on the base plate
1. Insert the threaded screws of the screw set for
fastening the pump
10
hexagonal holes in the base plate
2. Place the pump on the base plate
3
the threads protrude through the fastening
opening in the pump base.
3. Push the washer and then the serrated lock
washer over the screw thread.
4. Put on one winged screw each and tighten it.
The pump is mounted on the base plate.
5. Connect the base plate
The base plate is connected to the filter vessel.
Initial start-up of the timer
The timer is going to function flawlessly even if you do not perform the steps described below. However,
should the power supply be interrupted, the saved filter running times will be lost.
1. Make sure that the pump's power cable is disconnected from the power supply.
2. Undo the screws of the timer cover with a Phillips screwdriver PH1 and remove the cover.
3. Pull out the strip of plastic from underneath the battery.
4. Screw the cover back on.
The timer's memory backup function is activated.
Preparing the filter vessel
1. Undo the locking ring
purpose.
2. Put aside the locking ring and its screws.
from below into the two
.
9
so that
9
to the filter vessel .
9 2
by turning the screw counter-clockwise. Use the Allen wrench
5
1
for this
