If you forget your Dante Device Lock PIN, see the Device Lock section of the Dante Controller User Guide for instructions on
how to proceed.
Dante Domain Manager
Version 1.2.X introduces support for Dante Domain Manager (DDM) for AD4D and AD4Q. DDM is network management soft­
ware that enables user authentication, role based security, and audit capabilities for Dante networks and Dante­enabled pro­
ducts.
Considerations for Shure devices controlled by DDM:
• When you add Shure devices to a Dante domain, leave the local controller access setting in Read Write. Otherwise, ac­
cess to Dante settings, device factory reset, and device firmware updates will be disabled.
• When a device is managed by a Dante Domain and the Dante Domain is disconnected, access to Dante settings, device
factory reset and device firmware updates will be disabled. When a device reconnects to the Dante Domain, it follows the
policy set for it in the Dante Domain.
See the Dante Domain Manager User Guide for more information.
Networking Modes and Switch Configuration
The receiver offers two selectable networking modes:
• Split/Redundant: This mode places Dante audio and Shure control on separate networks, while allowing you to take ad­
vantage of Dante redundancy.
• Switched: In Switched mode, the receiver acts as a 4-port network switch. Shure control and Dante audio are present on
all network ports.
Port Function and Signals
Network
Mode
Port 1
Shure con­
SWITCHED trol, Dante
primary
SPLIT/RED­
UNDANT Shure con­
(Factory trol
setting)
Port 3 (Pri­
Port 2
mary)
Shure con­ Shure con­
trol, Dante trol, Dante
primary primary
Shure con­ Dante prima­
trol ry
Application
Port 4 (Secon­
dary)
Shure control, For single network installations of star or
Dante primary daisy-chained networks.
Primary and secondary ports are configu­
Dante secon­ red are separate networks to provide isola­
dary tion between control signals and audio si­
gnals.
