oPeRat InG the MaChIne
2.
2.1
2.2
2.3
2.4

Operating the Machine

Range of applications of the CT 200®
Information
The CT 200® has been specifically designed developed for the milling or scarifying of hori-
zontal dry floors such as concrete and steel surfaces with and without coatings and for as-
phalt using the milling tools offered exclusively by CONTEC® .
Specifically for use outside in dry weather. The operation is only permitted with a dust ext-
raction system recommended by CONTEC® .
Operational function of the CT 200®
The CT 200® performs aggressively when removing concrete, asphalt, coatings and road
markings. Specially designed milling flails make it easy to remove flexible plastic coatings,
epoxy resins and road markings.

Application of the tools

Tools
TCT Cutters
Milling cutters
Beam flails

Operating and scarifying

After mounting the appropriate tools the operation of the scarifier / planer can begin.
f The height adjustment lever (see chapter 2.7 Height adjustment of the tool drum) must
be in the upper position before the motor is switched on. In addition, the handwheel of
the machine must be turned anti-clockwise as far as it will go.
f Switch on the motor.
In the case of petrol version, open the petrol tap and start the engine by hand. (See
operating instructions)
f Lower the planer by pushing the quick height adjustment lever down.
f Adjust the working depth with the handwheel of the height adjustment until the tools are
lowered to the floor and until the required finish is achieved.
f Attention: Never switch the motor of the planer on while the tools still touch the floor.
Always lift the machine and the tools clear from the floor and then switch the motor on.
f Heavy dust formation can be avoided by connecting an extraction system.
f The damping of the operator›s grip enables almost vibration-free work
Application
Heavy duty, long life cutters for all concrete texturing,
scabbling, planing and grooving applications. Also
used for removal of road markings, roof chippings and
brittle coatings
Primarily for the removal of thermoplastic road / run-
way markings. Tipped with tungsten carbide they are
cost effective and highly efficient. A range of cutter di-
mensions are available
Heat treated cutters for the removal of paint coatings
and laitance from new concrete. Also for removing
grease, dirt and ice deposits.
