Installation and Operating Instructions
CHAPTER 7
OPERATING
OPTIONS
Central ventilation unit – KWL 250 W/W ET
7.1

Local web server

The unit can be configured via the local web server using a web browser, via a mobile end device (e.g. notebook, PC,
tablet, smartphone). A unit login/registration is not required.
Set up local web server:
1. Connect unit to the router or directly to a notebook/PC via an Ethernet cable RJ45 (not included in delivery).
2. Open desktop and click on Network, cf. Fig. 32.
ⓘ Network discovery must be activated!
3. Double-click on the corresponding unit, cf. Fig. 32.
> The easyControls 3.0 controls open automatically via the web server in the web browser.
4. Configure unit settings, see chapter 8.1 „Menu overview", page 23.
ⓘ In order to operate the unit, the commissioning assistant must be complete, see chapter 6.2 „Run commissio-
ning assistant", page 16.
7.2

easyControls 3.0 cloud service

Users, service technicians or housing associations can change external unit settings or call up status information via
the easyControls 3.0 cloud service at any time. Registration with a username and password is required to use the ea-
syControls cloud service.
ⓘ The initial connection to the cloud service must take place via the local web server of the KWL
reasons.
The easyControls 3.0 cloud service is accessible via the website www.cloud.easyControls.net
ⓘ The KWL
unit must be connected to the internet.
®
7.3

Control element

The operating or control options for the KWL
(accessories) or the comfort control element KWL-BE Touch (accessories).
The installation, commissioning and detailed functional description can be found in the installation and operating inst-
ructions for the corresponding control element.
ⓘ A software update can be performed via the control element KWL-BE Touch.
7.4

Building control system

The KWL® unit can be integrated in a building control system network via the standard Modbus interface (RS 485) or
an optionally available KNX module KWL-KNX Connect (accessories).
ⓘ The associated operating instructions "KWL
www.HeliosSelect.de in the corresponding article.
Fig. 32
unit can be extended via the slide switch control element KWL-BE Eco
®
easyControls Modbus" can be downloaded on HeliosSelect at
®
22
EN
unit for security
®
