Motor has no oil-filling !
Motor protection
The pump is equipped with an electronic monitoring system (MD-Electronic System)
that monitors phase sequence (rotating), motor temperature, voltage, frequency and
phase failure.
The pump has a build-in moisture sensor (MD-Sensor) which detects a water
inleakage and switches off the pump immediately. The user don't have to
check the shaft seal for leak- tightness!
In case of a breakdown the pump turns off. After troubleshooting the pump has to be
restarted by switching-on the rotary knob on the motor-protection plug.
4.2

Technical Characteristics

Flow l/min. (gal. (US))
(acc. to DIN 1944)
at head m / ft.
(10 m WC = 1 bar)
(32,8 ft. WC = 1 bar)
Voltage
Rated power
Shaft power
Rated current
Protection category
Grain passage
Discharge conn. size / coupl.
Power conn. line 20 m H07RN-F
Liquid temperature
Liquid density
Immersion depth
ph-value of liquid
Weight without conn. line kg (lbs.)
Weight with conn. Line
20
TP 8-1 N
l/min (gal)
1350 (356)
1200 (317)
950 (251)
560 (148)
0
V 400
P kW 3,3
1
P kW 2,7
2
A 5,8
DIN EN 60529 - IP 68
Ø mm (inch) 10 (0,4)
G 2 1/2 " / STORZ B
4 G 1,5
°C °F max. 60°C / 140 °F
3
kg/dm max. 1,1 kg/dm
m / ft.
max. 20 m / 65,6 ft.
5 - 8
27 (59)
kg (lbs.) 32 (70)
Submersible pump TP 8-1 N
m (ft.)
0
5 (16,4)
10 (32,8)
15 (49,2)
20 (65,6)
