5.2

Electrical connection

➢ Observe the
Safety
Installation:
➢ Loosen the four cross-head screws in the lens and remove them upwards.
➢ The holes for mounting the housing are then accessible, for dimensions see chapter
native installation possible with the brackets supplied.
➢ Perform electrical connection on the circuit board in the lens as follows:
X1
Operating voltage
connection
AC:
DC:
X2 S1
External control in- Selection of
put operating mode
Note: Devices with DC voltage are equipped with reverse polarity protection. The function is guaranteed if the
polarity of the connections is reversed.
➢ Only cable glands with a degree of protection of at least IP66/ IP67 should be fitted to the corresponding
openings.
➢ Secure the connecting cables against pulling and twisting during installation.
➢ Close the device again after connecting the cables.
➢ Carry out a final functional test to ensure reliable signaling.
10/2020
information!
115 – 230 V AC/ 115 – 230 V DC
Light intensity
control
(15 - 100%)
Connection of
the line
DC version (12 – 48 V)
Light intensity control
(15 - 100%)
Operating Instructions Quadro LED-HI
S1,
Selection of operating mode
S1
1 2 3
OFF OFF OFF
OFF OFF ON
OFF ON OFF
OFF ON ON
ON OFF OFF
ON OFF ON
ON ON OFF
ON ON ON
X1
Operating voltage
connection
Seite 1 / 6
3. Dimensions.
Operating
mode no.
1 Flashing light 0.75 Hz
2 Flashing light 1 Hz
3 Continuous light
4 Blinking light
5 Flashing light 2 Hz
6 Blinking light
7 Flashing light 0.1 Hz
8 Flashing light 0.5 Hz
Connection
of the line
Alter-
1 Hz
2 Hz
