3. Usage and Operation
3.2 Direction bar and child seat adjustment
Adjust the freight of the direction bar
- First, open the quick release handle and rotate the loose nut. Adjust
the direction lever to the appropriate height according to your height.
After the adjustment is completed, tighten the nut and lock the quick
release handle. (Picture 7, 8, 9)
- When adjusting the steering bar, care should be taken not to expose
the safety marking the line of the directional tube riser.
Picture 7 Picture 8 Picture 9
Child seat opening and folding (Only for MS|3000)
Open: pull the red sphere backward, with one hand and lift the seat
upward with the other hand to open the child seat. (Picture 10-11)
Close: Pull down the red ball and press down the seat with the other
hand to fold the child seat. (Picture 12)
Picture 10 Picture 11 Picture 12
