3. Usage and Operation
3.1 Folding and unfolding steps
Seat assembly and removal
Seat Assembly: Pick up the seat, first insert the slot behind the seat
into the bracket behind the seat, pull the bar under the seat, and insert
the groove in the front of the seat into the bracket in front of the seat.
The small bracket can be adjusted forward and backward. Seat posi-
tion.
Seat disassembly: Pull the bar under the seat and lift the seat up to
remove the seat
Folding (MS|3000 PLUS)
- Stop the MS|3000 PLUS on a flat place, remove the seat before
folding, and pull up the large red ball on the right to fold it successfully.
- After folding, you can pull the MS|3000 PLUS direction bar to tow it.
If you need to put it in the car or transport it, you can open the quick
release handle of the direction bar and rotate the loose nut to adjust to
the lowest height. (Check section 3.2)
Unfolding (MS|3000 PLUS)
- After pulling the lower small red ball to unlock the folding lock, pull
the back end away from the front to flatten out the scooter, then install
the seat.
