2. Hold the pole in place and measure the length required. For best results the lens of the
projector should be a few inches above the axis with the top of the screen.
3. Cut pole to length at ground level using a pipe cutter.
4. You will need to drill new holes in the end of the pole:
a. Fit the drilling jig onto the end of the pole which has just been cut.
b. Use the included Hex key to tighten jig onto the pole.
c. Place the jig and pole on the ground. Hold down with one foot and drill.
d. Remove jig.
1. Projector
2. Screen
1. Pole
2. Hex Bolt
3. Drilling jig
