Assemblée pour l'option C
1. Use the M8 bolts and Rawl plugs included to fi x top yoke to the ceiling.
For concrete ceilings use appropriate fi xings.
2. Attach the projector to the spider/bottom yoke fi tting to the projector, and attach all
to the top piece of the tilting mechanism. Fix one end of fall-arrest cable to pole, and the
other end to projector.
1. Support Universel "Spider"
2. Projecteur
3. Mécanisme Sommet
4. Câbles d'entrée
5. Cable de sécurité anti-chute
1. Poteau
2. Chevilles plastiques
pour fi xation plafond
3. Boulons M10x25
4. Palonnier de plafond
5. boulon de plafond
