5 Cleaning and Maintenance

5.1 Description of the Components

Fix screw (1)
Outer housing (2)
Volume
switch (3)
Adaptor ring (4)
Cap nut (5)
Cannula holder (7)
Ejection valve (11)
Valve axle (12)
O-Ring b (14 b)
All manuals and user guides at all-guides.com
Calibration screw (3.1)
rocker
Indicator (3.2)
Counter nut (3.3)
Ejection cannula (6)
Suction valve (8)
edges on top!
Valve star (9)
Ceramic ball (10)
Closing cap (13)
O-Ring a (14 a)
witeg Labortechnik GmbH, Dispenser LABMAX "airless"
