3.2 Steckerbelegung von CN1
Vcc:
Interne Versorgungsspannung (+ 5V) des Rechners (nur durch Einlöten eines Widerstan-
des an B11). Hier niemals eine externe Spannung anlegen.
GND:
Masse des Rechners (nur durch Einlöten eines Widerstandes an B12)
OPTOIO-PCI32
© 2002-2011 by Messcomp Datentechnik GmbH
STANDARD
GND
Vcc
68
34
GND
Vcc
67
33
OUT31-
OUT31+
66
32
OUT30-
OUT30+
65
31
OUT29-
OUT29+
64
30
OUT28-
OUT28+
63
29
OUT27-
OUT27+
62
28
OUT26-
OUT26+
61
27
OUT25-
OUT25+
60
26
OUT24-
OUT24+
59
25
OUT23-
OUT23+
58
24
OUT22-
OUT22+
57
23
OUT21-
OUT21+
56
22
OUT20-
OUT20+
55
21
OUT19-
OUT19+
54
20
OUT18-
OUT18+
53
19
OUT17-
OUT17+
52
18
OUT16-
OUT16+
51
17
OUT15-
OUT15+
50
16
OUT14-
OUT14+
49
15
OUT13-
OUT13+
48
14
OUT12-
OUT12+
47
13
OUT11-
OUT11+
46
12
OUT10-
OUT10+
45
11
OUT09-
OUT09+
44
10
OUT08-
OUT08+
43
9
OUT07-
OUT07+
42
8
OUT06-
OUT06+
41
7
OUT05-
OUT05+
40
6
OUT04+
OUT04-
39
5
OUT03-
OUT03+
38
4
OUT02-
OUT02+
37
3
OUT01-
OUT01+
36
2
OUT00-
OUT00+
35
1
wasco
®
DV05
