ADDITIONAL INFORMATION RELATING TO UL APPROVALS:
For use in Pollution Degree 2 Environment
Technical data
according to EN/IEC 61557-1
Degree of protection
housing
terminals
according to EN/IEC 61557-8
Internal impedance Z i at 50 Hz
Peak value of U m
Max. value of I m
Max. system leakage capacitance C e
Max. DC voltage U fg
Test voltage
supply circuit / output circuit
supply circuit / measuring circuit
measuring circuit / output circuit
Electrical data for the contact circuits and the interface
Min. switching voltage / current
Max. switching voltage / current
Rated operational current (EN/IEC 60947-5-1)
AC12 (resistive) 230 V
AC15 (inductive) 230 V
DC12 (resistive) 24 V
DC13 (inductive) 24 V
Internal resistance R i of the
measuring circuit
Do not connect the CM-IWN.x in parallel !!
*
CM-IWN.6 does not meet the requirements of EN/IEC 61557-8 regarding the
response time t
.
an
(D)
Produkt anbringen
(GB) Fix product
(F)
Montage du produit
(E)
Fijar el producto
(I)
Montare il prodotto
(RU)
(CN)
CM-
CM-
CM-
IWN.1
IWN.4
IWN.5
IP50
IP20
min.
155 kOhm
24 V +10 %
0.15 mA
20 μF
500 μF 1000 μF
460 V DC
2.32 kV 50 Hz, 2 s
2.32 kV 50 Hz, 2 s
2.53 kV 50 Hz, 1 s
24 V / 10 mA
see load limit curves in data sheets
4 A
3 A
4 A
2 A
min.
185 kOhm
(D)
Produkt entfernen
(GB) Remove product
(F)
Démontage du produit
(E)
Desmontar el producto
(I)
Rimuovere il prodotto
(RU)
(CN)
(D)
Plombierbare Klarsichtabdeckung anbringen
CM-
(GB) Fix sealable transparent cover
IWN.6*
(F)
Fixation du capot transparent condamnable
(E)
Fijar cubierta transparente sellable
(I)
Fissare la copertura trasparente sigillabile
(RU)
(CN)
2000 μF
1
(D)
Mindestabstand zu anderen Geräten
(GB) Minimum distance to other units
(F)
Espacement par rapport aux autres modules
(E)
Espacio mínimo entre módulos
(I)
Spazio tra un modulo e l'altro
(RU)
(CN)
Bei dauernd anliegender Spannung von > 400 V ist ein seitlicher
Geräteabstand von mindestens 10 mm (0,39 in) einzuhalten!
In case of continuous measured voltage > 400 V, lateral spacing
to other units has to be min. 10 mm (0.39 in)!
Dans le cas d'une tension permanente mesurée > 400 V,
l'espacement latérale par rapport aux autres modules doit être
de 10 mm (0,39 in) au minimum!
Para tensiones de medida continuas > 400 V dejar un espacio
lateral entre módulos como mínimo de 10 mm (0,39 in)!
Nel caso in cui la tensione sottoposta a misura fosse di continuo
> 400 V, lo spazio laterale tra un modulo e l'altro deve essere
min 10 mm (0,39 in)!
2
2
3
4
> 400
2
