QMC41-100-I06
This partly completed machinery must not be put into service
until the final machinery into which it is to be incorporated
has been declared in conformity with provisions of The Sup-
ply of Machinery (Safety) Regulations 2008 S.I. 2008/1597,
where appropriate.
The following (parts/clauses of) Designated Standards have
been applied:
EN 61000-3-3:2013 , EN 61000-6-2:2005 + AC:2005 , EN
61000-6-3:2007 +A1:2011 , EN 61010-1:2010 , EN
61326-1:2013, EN 61000-3-2:2014
The relevant technical documentation was compiled and was
communicated in accordance with The Supply of Machinery
(Safety) Regulations 2008 S.I. 2008/1597 part B of Annex
VII. Authorities can request the technical file in electronic
form from:
Aleksandra Duric, Product Compliance Manager, Atlas
Copco Industrial Technique AB, SE-105 23 Stockholm Swe-
den
Stockholm, 1 September 2023
Håkan Andersson, Managing Director
Signature of issuer
Authorised Representative UK
James McAllister, General Manager
Atlas Copco Ltd
Swallowdale Lane
Hemel Hempstead
Hertfordshire HP2 7EA
Safety
DO NOT DISCARD - GIVE TO USER
WARNING Read all safety warnings, instructions, il-
lustrations and specifications provided with this prod-
uct.
Failure to follow all instructions listed below may result
in electric shock, fire, property damage and/or serious in-
jury.
Save all warnings and instructions for future refer-
ence.
WARNING All locally legislated safety rules regard-
ing installation, operation and maintenance shall be
respected at all times.
Statement of Use
• For professional use only.
• This product and its accessories must not be modified in
any way.
• Do not use this product if it has been damaged.
© Atlas Copco Industrial Technique AB - 9834 3502 00
• If the product data or hazard warning signs on the product
cease to be legible or become detached, replace without
delay.
• The product must only be installed, operated and serviced
by qualified personnel in an industrial environment.

Intended Use

This product is designed for installing and removing threaded
fasteners in wood, metal or plastic.
No other use permitted.
Product Specific Instructions
Storage and Transport
Storage and transport
• The components should be stored at a dry place, and
should be protected from dust and aggressive media.
High variation of temperature should be avoided.
• Each connection should be removed before transport to
avoid breaking the connecting cables.
Use sufficient insulation of the shipping packet to protect
components against damage.
Installation
Installation safety
• Refer installation to qualified personnel only.
• Always connect the system to an earthed outlet.
• Always make sure that the mains plug is disconnected
and the controller is turned off before connecting or dis-
connecting the tool cable.
Operation
Operation
1. Pull the chuck ring outwards
2. Insert the bit
3. Turn the bit, if not seated properly
Safety precautions
• This product shall only be operated indoors in dry rooms.
• This product must not be used in explosive atmospheres.
• The product must only be operated by a qualified person
in an industrial assembly environment. Make sure that the
tool bit does not come in contact with the conductors in
the controller cord, or any other concealed conductors or
live electrical parts.
Safety Information
