Next Level Racing ELITE Serie Montageanleitung Seite 5

IN THE
BOX
1 x YOKE PLATE
1 x CENTRE POLE BRACKET
2 x FLIGHT ARM MOUNTS
2 x LOCKING CORNER BLOCKS
4 x M8 35mm LOW PROFILE BOLTS
NOTE: Some Items Come with
Rust Resistant Coating
*NOT TO SCALE
2 x FLIGHT PLATES
1 x CENTRE POLE MOUNTING ARM
2 x FLIGHT ARM MOUNTING PLATES
2 x CORNER BLOCKS
3 x M8 SHOULDER BOLTS
5
Video Instruction: bit.ly/nlrbuild
1 x SPACER PLATE
1 x CENTRE POLE ADAPTOR
2 x FLIGHT ARMS
14 x REGULAR T-NUTS
14 x WIDE FULL WIDTH T-NUTS
6 x M6 (10mm) NYLON SPACERS
1 x HOTAS PLATE
1 x HOTAS ANGLE BRACKET
2 x EXTRUSION END PLATES
2 x M8 60mm BOLTS
8 x M6 60mm BOLTS
8 x M5 60mm BOLTS
2 x M8 16mm RATCHET HANDLES
