Raised Seat (For Setups With Rudders) - Next Level Racing ELITE Serie Montageanleitung

)
A
Repeat
on Other
Side
A) Align the slots on the corner brackets with T-Nuts previously installed in Step 22(a) & Step 23(a).
25
B) Bolt through and secure with 1 x M8 Bolt and Washer.
C) Bolt through and secure with 1 x M8 Bolt and Washer.
RAISED SEAT INSTALLATION
(Recommended if using Rudders)
)
A
26 A) Uninstall the Bolts securing the Seat Brackets to the Seat Sliders.
B) Remove the Seat Brackets.
)
A
27
A) Uninstall the Ratchet Handles securing the Seat Sliders to the Base Frame.
B) Uninstall the Bolts securing the End Plates to the Seat Sliders.
Video Instruction: bit.ly/nlrbuild
)
B
Repeat
on Other
)
C
Repeat
on Other
)
B
)
B
19
PARTS:
• • 2 x Corner Blocks
Side
• • 4 x M8 16mm Bolts
Side
• • 4 x M8 Washers
PARTS:
• • NIL
PARTS:
Repeat
• • NIL
on Other
Side
