Pin connection for pluggable sensors

4
1

Electrical connection

Disconnect the system from power. Then connect the device according to the connection
diagram.
The indicated load needs to be considered and should not be more or less.
Pin connection for pluggable sensors (topview)
3
4
5
1
2
3
The protective earth-terminal
i
(Pin 5) is only available for
sensors with metal housing
and for StEx version
2
