Technical Data - Jung SV-SERVER Bedienungsanleitung

Scope of delivery
- Smart Visu Server including software
- Retaining bracket for wall or support rail mounting
- Operating instructions
- Power supply unit with plug
- SV-SERVER:
- SV-SERVER-INT: Power supply unit, including adapter for BS (United Kingdom),
Legal information
Philips and Hue are registered trademarks of Koninklijke Philips Electronics NV.
This product contains Open Source software components, which are subject to the
conditions of Copyright and/or the license agreements of third parties.
The license information is located on the Smart Visu server.

Technical data

Rated voltage:
Power consumption:
Ambient temperature:
Storage/transport temperature:
LAN:
USB:
Dimensions:
Power supply unit with plug
Primary voltage:
Mains frequency:
Rate current:
Secondary voltage:
Protection class:
Length of connecting cable: 1.5 m
Plug contact:
CAUTION
This device contains a battery (CR1632, 0.4 Wh) to back up the saved data.
Do not dispose of discharged batteries with domestic waste. During trans-
port, comply with the special regulations of the ADR and IATA.
EU power supply unit (Euro plug)
EU (Euro plug) and CN (China)
DC 12 V SELV
Typ. 3 W, max. 7 W
–5 ... +45 °C
–25 ... +70 °C
RJ45 socket (10/100 Mbit/s Fast Ethernet) CAT5
USB 2.0 Host
124 x 72 x 31 mm (without retaining unit)
124 x 92 x 40 mm (with retaining unit)
AC 100 ... 240 V ~
50 / 60 Hz
max. 1 A
DC 12 V SELV
II
- SV-SERVER:
- SV-SERVER-INT: BS, EU, CN
EU
EN
11
