Technical Data - GRAPHITE 58G794 Übersetzung Der Originalanleitung

7. Extension
8. Bits
DESCRIPTION
The cordless drill / driver is a hand-held power tool with protection class
II. The area of its application is the performance of renovation and
construction works and all works in the field of independent amateur
activity. The drill driver can be used with a range of sockets, screwdriver
bits and bits of various lengths that have 1/4 '' hexagonal shanks. It is
possible to use the device both as a screwdriver and in cooperation with
drill bits with 1/4 '' hexagonal shank, for light drilling works.
CONTENTS
Drill driver 1 pc.
Extension 1 pc.
Bits 5 pc.
Manual 1 pc.
Guarantee card 1 pc.
OPERATING
Turn on / off
The mains voltage must correspond to the voltage specified on the
screwdriver's rating plate.
• Switching on - press the switch button and hold it in this position. •
Switching off - release the pressure on the switch button If the lockout
button is pressed while the trigger switch is pressed, the tool will remain
on even after the trigger is released. To turn the device off, press and
release the trigger switch again.
Speed regulation
To increase the speed, turn the speed control knob clockwise and to
decrease it, turn it counterclockwise.
Reversing the direction of rotation
The direction of rotation of the screwdriver spindle is selected using the
rotation selector.
Clockwise Rotation - Move the rotation direction switch to the left side
of the tool.
Counterclockwise rotation - Move the rotation direction switch to the
right side of the tool.
The engine must not be running while the lever is being changed. Do
not press the rotation direction button with the trigger switch pressed.
Insertion and removal of bits
Removing and installing bits should be performed with the device turned
off and the plug removed from the socket.
•
Place the bit in the magnetic head. No tightening is required.
•
The bit is removed by removing it from the head.
Screw depth adjustment
For precise depth adjustment, hold the depth adjustment head. Turning
the head clockwise shortens the spindle. Turning the head
counterclockwise will extend the spindle.

TECHNICAL DATA

Corded drill driver 58G794
Parameter
Rated voltage
Frequency
Rated power
Rotational speed
Bits size
Protection class
Ingress protection
Mass
Year of production
58G794 defines type and indication of the device
NOISE AND VIBRATION
Sound pressure level
Measured sound power level
Value
230 V AC
50 Hz
520 W
-1
0-4200 min
¼"
II
IPX0
1,66 kg
2023
L = 99 dB(A) K=3dB(A)
PA
L = 88 dB(A) K=3dB(A)
WA
Vibration acceleration value
Information on noise and vibration
The level of noise emitted by the device is described by: the level of the
emitted sound pressure L
the measurement uncertainty). The vibrations emitted by the device are
described by the value of the vibration acceleration a
measurement uncertainty).
The following information: emitted sound pressure level L
power level L and vibration acceleration a
wA
accordance with EN 62841-1:2015. The given vibration level a
used to compare devices and for a preliminary assessment of vibration
exposure. The stated vibration level is representative only for the basic
use of the device. If the machine is used for different applications or with
different working tools, the vibration level may change. The higher level
of vibrations will be influenced by insufficient or too rare maintenance of
the device. The reasons given above may result in an increased
exposure to vibration during the entire period of operation.
To accurately estimate exposure to vibration, consider periods
when the equipment is turned off or when it is turned on but not in
use. After all factors have been carefully assessed, the overall
vibration exposure may be significantly lower.
In order to protect the user against the effects of vibrations, additional
safety measures should be implemented, such as: periodic
maintenance of the device and working tools, protection of the
appropriate temperature of hands and proper organization of work.
ENVIRONMENT PROTECTION
Do not dispose of electrically powered products with
household wastes, they should be utilized in proper plants.
Obtain information on waste utilization from your seller or local
authorities. Used up electric and electronic equipment
contains
Unrecycled equipment constitutes a potential risk for
environment and human health.
"Grupa Topex Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with
seat in Warsaw at ul. Pograniczna 2/4 (hereinafter Grupa Topex) informs, that all
copyrights to this instruction (hereinafter Instruction), including, but not limited to, text,
photographies, schemes, drawings and layout of the instruction, belong to Grupa
Topex exclusively and are protected by laws accordingly to Copyright and Related
Rights Act of 4 February 2004 (ustawa o prawie autorskim i prawach pokrewnych, Dz.
U. 2006 No 90 item 631 with later ammendments). Copying, processing, publishing,
modifications for commercial purposes of the entire Instruction or its parts without
written permission of Grupa Topex are strictly forbidden and may cause civil and legal
liability.
EC Declaration of Conformity
Manufacturer: Grupa Topex Sp. Z o.o. Sp.k., ul. Pograniczna 2/4
02285 Warszawa
Product: Corded drill driver
Model: 58G794
Commercial name:
Serial number: 00001 ÷ 99999
This declaration of conformity is issued under the sole responsibility of
the manufacturer.
The product listed above is in conformity with the following EU
Directives:
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EU
RoHS Directive 2011/65/EU as amended by Directive 2015/863/EU
And fulfills requirements of the following Standards:
EN 62841-1:2015; EN 62841-2-2:2014;
EN IEC 55014-1:2021; EN IEC 55014-2:2021; EN IEC 61000-
32:2019+A1; EN 61000-3-3:2013+A1+A2;
EN IEC 63000:2018
This declaration relates exclusively to the machinery in the state in
which it was placed on the market and excludes components which
are added and/or operations carried out subsequently by the final
user. Name and address of the person residing or established in the
EU and authorized to compile the technical file:
5
a = 1,711 m/s
h
m/s
and the sound power level L
pA
h
were measured in
h
substances active in natural
GRAPHITE
2
K=1,5
2
(where K is
wA
(where K is the
, sound
pA
can be
h
environment.
