TECHNICAL DATA

6. TECHNICAL DATA
TECHNICAL DATA:
Electrical:
Supply voltage
Mains frequency
Output voltage, mains operation
Output voltage, battery operation
Max. continuous output current during mains operation
Max. motor current: (E.g. 2 houses, each with 2.1A on one
DOL 78. Simultaneous motor operation in both houses is ac-
ceptable for a max. of 20% of the time and for 10 minutes at a
time).
(E.g. 1 house with 4.2A on one DOL 78. Motor operation is
acceptable for a max. of 20% of the time and for 10 minutes at
a time).
Battery Standby charge voltage
Max. battery charge current
Battery fuse (Blue "car type" fuse with flat type connector)
TEST lamp OK level
Battery module, gastight lead
Adjustment interval
Opening period interrupted, DOL 12
o
Opening period at 1 C excess temp.
o
Opening period at 5 C excess temp.
Max. DOL 78T battery operating time (without motor operat.)
Temperature sensor inputs
Relay outputs, +24V, time modulated
Fuse per 24V relay output (Brown "car type" fuse with flat type
connector)
Synchronization output, battery check pause / test time
Environment:
Temperature, operation
Temperature, storage
Protection class
EMC immunity
EMC emission
Mechanical:
Max. cable length, DOL 78T - DOL 34H / DOL 36
Dimensions
Dimensions, packaged
Weight, DOL 78T
Weight incl. packing, DOL 78T
01.04.97
DOL 78T-1 Common
230/240V AC ± 10%
50/60 Hz
24V DC ± 30%
15-18V DC
2.1 A
4.2 A
20.5V
1.5A
15A
>16V
18V 4Ah (3 x 6V 4Ah)
3 min. +/-20%
10 sec.+/-30%
5 sec.+/-30%
30 sec. +/-30%
4 - 8 hours
1 x DOL 12
2 x +24V
7.5A
3 min. / 5 sec.
10°C
25°C
IP 54
EN 50081-2 Industry
EN 50082-2 Industry
3 m
HxWxD 325x280x127 mm
LxWxH 370x335x265 mm
8.8 kg
6.4 kg
PAGE 22
DOL 78T-2
2 x DOL 12
4 x +24V
+45°C
+60°C
DOL 78T MANUAL
