4
INSTALLATION

4.1.3 Installation of battery in DOL 78T

Mark the enclosed battery date label with a cross and stick it on the battery module
module on the shelf

4.1.4 Installation of TEST mains disconnector

Place the TEST mains disconnector
DOL 78T detects power failure on its own mains supply. DOL 78T must therefore be supplied from the
same phase as DOL 34H`s / DOL 36`s house-1 mains connection terminal 23.

4.1.5 Installation of temperature sensor in the house

Place the DOL 12 temperature sensor next to the climate computer indoor temperature sensor, which is
also a DOL 12.
If the climate control temperature sensors have not yet been installed, install the DOL 78T sensor:
1 metre above the animals at the centre of the house.
N
In a zone without draught which is not directly exposed to heat radiation and which is not the last one
N
to be heated.
Where sunbeams do not reach the sensor through the windows. Remember that the position of the sun
N
varies with the season.

4.1.6 Installation of filter module in the climate control unit

There are 2 cabinet sizes for the climate computers with each their installation method. See fig. : DOL
34H-1 or fig 4.4: DOL 34H-2 / DOL36.
DOL 34H-1 with narrow cabinet: Install the filter module over the empty space on the relay panel.
N
DOL 34H-2 or DOL 36 with wide cabinet: Install the filter module to the right of the large relay panel.
N
The module MUST be fastened thoroughly by means of the screws in the threaded groove at the bottom.
Remove the short-circuit connection at the text "EMERGENCY OPENING" on the climate computer
connection module, and insert the corresponding connector from the filter module-EMC instead. Insert
the two identical connectors of the filter module, labelled (1) and (2), in the IN/OUT module connections
labelled "T1" and "T2". If there is no IN/OUT module, insert the connectors in the relay panel connecti-
ons labelled RELAY-1 and RELAY-2.
01.04.97
in the DOL 78T cabinet. The battery must NOT be connected yet.
next to DOL 78T so that unintentional activation is avoided.
PAGE 8
. Put the battery
DOL 78T MANUAL
