Driver Installation - Icy Box DisplayLink IB-DK2288AC Handbuch

Legacy USB standards
USB 3.0 = USB 3.1 (Gen 1) = USB 3.2 Gen 1
USB 3.1 = USB 3.1 (Gen 1) = USB 3.2 Gen 1
USB 3.2 (Gen 1x2)
Requirements
• USB Type-C
• Power Delivery and DP Alt Mode support
• Maximum resolution of 4K@60 Hz only via Type-C
supported host computers with DP 1.4 (DSC)
• The device is compatible with Thunderbolt
USB Type-C
®
Not all USB Type-C® host ports support the full functionality of the USB Type-C®
standard. Some ports might only provide data transfer without supporting Power
Delivery over USB.
DisplayPort
™
Alt Mode
Computer
manual
To use this dock to its full potential, ensure that the USB Type-C® host port of your
computer supports USB Power Delivery or Thunderbolt™ 3 / 4.

Driver installation!

Caution: Do not connect the DockingStation to your computer before installing the
driver from the download area of:
https://www.synaptics.com/products/displaylink-graphics/downloads
1. Select your operating system and download the correct driver
from the webpage mentioned above.
2. Click on the executable file of the related version.
3. Follow the instructions and finish the driver installation.
4. Connect the DockingStation to a supported USB Type-C® port of the PC.
5. Restart the PC.
6. The IB-DK2288AC is ready for use.
Manual IB-DK2288AC
USB version information
Current USB standards
= USB 3.2 Gen 1x2
enabled Windows
®
USB Type-C
Important!
This ICY BOX product requires the usage of DisplayPort™ Alt Mode
technology over the USB Type-C™ connector. Not all computers,
notebooks or tablets with a USB Type-C™ interface support the
DisplayPort™ Alt Mode.
Please check the specifications of your computer system as
well as its USB Type-C™ interface or use the ICY BOX product with a
Thunderbolt™ 3 connector.
= 5 Gbit/s
= 5 Gbit/s
= 20 Gbit/s
/ macOS computer
® ®
3 / 4 equipped computers
™
≠
USB Type-C
™
Data transfer rate
DP Alt Mode
®
™
