If you are using controllers with this occupation, you can connect the DMX output of the controller directly
with the DMX input of the first device in the DMX chain. If you wish to connect DMX controllers with other
XLR outputs, you need to use adapter cables.
Building a serial DMX chain:
Connect the DMX output of the first device in the DMX chain with the DMX input of the next device. Always
connect one output with the input of the next device until all devices are connected.
Caution: At the last fixture, the DMX-cable has to be terminated. Plug the terminator with a 120
between Signal (–) and Signal (+) in the DMX-output of the last fixture.
Master/Slave operation
The master/slave operation enables that several devices can be synchronized and controlled by one master
device.
On the rear of the device you can find a 3-pin XLR connector for DMX-input and a 3-pin XLR plug for DMX-
output, which can be used for connecting several devices.
Choose the device which is to control the effects. This device then works as master device and controls all
other slave devices, which are to be connected to the master device via a DMX-cable. Connect the OUT jack
with the IN plug of the next device.
Set DIP Switch 10 to 0 in order to determine the Master device, then choose the desired mode. (see
OPERATION).
Connection with the mains
Connect the device to the mains via optional power supply cable.
The occupation of the connection-cables is as follows:
Cable
Pin
Brown
Live
Blue
Neutral
Yellow/Green
Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.
There is a power output connector and a power input plug on the rear panel. Connect one output with the
input of the next fixture until all fixtures are connected.
Please note:
A maximum of 8 LED Pixel Panels may be linked together. After every 8 LED Pixel Panels,
the fixtures must have a renewed connection with the power mains.
Note: This device is designed for vertical connections.
International
L
N
18/26
Ω
resistor
00062120.DOC, Version 1.1
