STAND ALONE-MODE

Automatic

In Auto Mode the internal program is called up automatically in a continuous loop.
Press the MODE button until the LED display shows "AUTO".
Please press the ENTER button to confirm.
To set the desired program speed, press the MODE button until the LED display shows "s---". The desired
speed (s001 - s100, increasing) can be selected via the UP or DOWN buttons.
Please press the ENTER button to confirm.

Sound Control

Press the MODE button until the LED display shows "SNd".
Please press the ENTER button to confirm.
You can do without a controller as the device features a built-in microphone, which provides automatic sound
control. You can adjust the sensitivity with the rotary-control on the rearpanel.

Master/Slave

Set the Master device to Automatic or Sound Control Mode and set each Slave device to the same DMX
mode CH2 or CH6.

DMX MODE

The LED display allows you to assign the DMX fixture address, which is defined as the first channel from
which the LED DMF-20 Hybrid Flower Effect will respond to the controller.
Addressing
Press the MODE button until the display shows one of the DMX modes CH2 or CH6, then press the ENTER
button to confirm.
Set the desired address via the UP or DOWN buttons (d001 - d512).
Please press the ENTER button again to confirm.
Controlling:
After having addressed the LED DMF-20 Hybrid Flower Effect, you may now start operating it via your
lighting controller.
Please see the following DMX protocol graphics for the respective channel values.

DMX-protocol

2-Channel Mode:
Channel 1 - Auto Programs
Value:
000 – 015
016 – 089
090 – 164
165 – 240
241 – 255
Channel 2 – SMD Strobe
Value:
000 – 000
001 - 255
Function:
Blackout
Auto program slow
Auto program middle
Auto program fast
Sound control
Function:
No function
Strobe with increasing speed
