Contents of Installation Readiness Manual
Introduction
Preparatory Works scheme
Fixing the tub to the wall
Water installation
Electrical installation
Bathroom walls, tiles,
pavement and decoration stripes
Dear customers,
TEIKO spol. s r.o. Spytihněv produces and delivers to the market the hydroairmassage baths in prices, which
do not include the cost for installation and putting into operation of all the equipment. Installation and putting
into operation is done by the installation fi rm, according to the customer's selection, this meeting the required
criteria of Teiko spol. s r.o. (see item 5, 6). For possible presentation of claims, it is presumed that the basic
installation instructions and procedures regarding the construction readiness of bathrooms are unconditionally
kept. That is why we recommend you to pay the maximum attention to the preparation of your bathroom for
installation of hydro-therapeutic equipment and that you keep all instructions shown in this manual. We wish
you a pleasant relaxing when using our products.
2.
Preparatory Works scheme - fi g. 1
The hydromassage bath tubs are installed into the completely prepared space of the bathroom. All construction works must
be completed. The power supply, water connection and waste piping must be totally completed. Also fl oors and walls must
be completed and equiponderant. The tiles must be glued roughly 100 mm inside into the space under the bath tub.
Installation bathroom readiness using the cover panel
1 - Possible outlet of wall tap
2 - Attachment of bath tub to the wall
3 - Space for outlet of warm and cold water (for pillar tap )
4 - Possible outlet of pillar tap
5 - Possible outlet of power supply (220V / 50 Hz). Necessary installations for hydromassage bath tubs of Elegance line
and additional system of FLUSHING and DESINFECTION
6 - Cold water outlet for disinfection and fl ushing
a) G3/4" under the bath tub, close to the inspection hole, fi nished with G 3/4" ball valve (effective for the systems : Basic,
Easy, Duo-Pneu, Duo, Duo Light, Excellent Hydro, Excellent Duo, Elegance Hydroair electronic, Elegance Magic Electronic)
b) G 1/2" under the bath tub, close to the inspection hole (effective for the systems: Elegance Hydro Pneu, Elegance Hydro
Electronic, Elegance Hydroair Pneu, Elegance Magic Pneu)
7 - Built-in closing valve serves to control the disinfection and fl ushing of the systems Elegance Hydro Pneu, Elegance
Hydro Electronic, Elegance Hydroair Pneu, Elegance Magic Pneu.
2.
Preparatory Works scheme - fi g. 2
The hydromassage baths are installed into the completely prepared space in the bathroom. All construction works must be
completed. The power supply, water connection and waste piping must be totally completed. Also fl oors and walls must be
completed and equiponderant. The tiles must be glued roughly 100 mm inside into the space under the bath tub.
Installation bathroom readiness without usage of the cover panel - oblong bath tub
1 - Possible outlet of wall tap
2 - Attachment of bath tub to the wall
3 - Space for outlet of warm and cold water (for pillar tap)
4 - Possible outlet of pillar tap
5 - Possible outlet of power supply (220V / 50 Hz)
6 - Installation holes with ventilation grid in the place where aggregates and control elements are positioned Necessary
installations for hydromassage bath tubs of Elegance line and additional system of FLUSHING and DESINFECTION
7 - Cold water outlet for disinfection and fl ushing
c) G3/4" under the bath tub, close to the inspection hole, fi nished with G 3/4" ball valve (effective for the systems : Basic,
Easy, Duo-Pneu, Duo, Duo Light, Excellent Hydro, Excellent Duo, Elegance Hydroair electronic, Elegance Magic Electronic)
10
Instructions for installation
page 10
of hydromassage bath tub
page 10, 11
Important Notice
page 12
Producer's recommendation
page 13
Survey of hydromassage bathtub types
page 13
page 13
– oblong bath tub
page 13
page 13
page 13
page 18, 19
