13
Align the mounting slots on the Left and Right Seat Frame with the middle mounting holes on the front
of the Seat Slider Assembly.
14
Bolt through the front holes and secure with 2 x M8 Bolts, Washers and Flange Nuts. Pull the Seat
Slider Handle upwards and slide the seat backwards when done.
15
Bolt through the rear holes and secure with 2 x M8 Bolts, Washers and Flange Nuts.
Repeat
on Other
Side
Repeat
on Other
Side
12
PARTS:
• • NIL
PARTS:
• • 2 x M8 20mm Bolts
• • 2 x M8 Ø20mm Washers
• • 2 x M8 Flange Nuts
PARTS:
• • 2 x M8 20mm Bolts
• • 2 x M8 Ø20mm Washers
• • 2 x M8 Flange Nuts
