User Code - Cosmo CSUS50STG Montage- Und Betriebsanleitung

8 4
S O L A R / E L E C T I V E F U N C T I O N S / E X T. H E
Factory
Designation
setting
Ext. HE
Output R4, B
Storage tank 1
Sensor HE S5
Target tem-
☐
perature
ΔTon
5.0 K
ΔToff
3.0 K
Overrun 2 min
I N S T A L L A T I O N / E L E C T I V E F U N C T I O N S / R M S
Factory
Designation
setting
Temp.maintenance
Output R5
Sen. return S8
Sen. source S7
ΔTon
5.0 K
ΔToff
3.0 K
☐
Summer off
Funct. Activated
8 . 9 . 6 U S E R C O D E
Factory
Designation
setting
Code 0000
Change to
The output for the secondary pump in the
transfer station is assigned here.
The solar charging of individual storage tanks
can be restricted here via the transfer station.
The sensor for the transfer station on the prima-
ry side before the heat exchanger is assigned
here.
A target temperature control can be activated
here.
Switch-on temperature difference for the
secondary pump of the transfer station
Switch-off temperature difference for the
secondary pump of the transfer station
Overrun time of the secondary pump of the
transfer station for use of residual heat.
Change to
The output for the return temperature mainte-
nance is assigned here.
The heat sink sensor for the return temperature
maintenance is assigned here.
The heat source sensor for the return tempera-
ture maintenance is assigned here.
Switch-on temperature difference for the return
temperature maintenance
Switch-off temperature difference for the return
temperature maintenance
Optional "Summer off" switch via an additional
sensor can be activated here.
The return temperature maintenance can be
temporarily deactivated here.
U S E R C O D E
Change to
Code 0000 = Display code.
No adjustments possible.
Code 0077 = End user code.
Adjustments are limited on the parameters
important for the end user.
Code 0262 = Specialist code.
All parmaters and functions can be changed.
Improper settings may result in damage to the
installation!
Note
Note
Note
