S O L A R T R A N S F E R S T A T I O N - 5 0 m
2
4 R E G U L A T I O N S /
S T A N D A R D S / D I R E C T I V E S
The station may only be used as a transfer station between the solar circuit and the heating
circuit in solar thermal systems, taking into consideration the technical limit values indicated in
these instructions. The solar transfer station is not suited for direct heating of potable water!
Due to its design, the station may only be installed and operated as described in these
instructions!
Only use C O S M O accessories with the transfer station.
Improper usage excludes any liability claims.
5 T E C H N I C A L D A T A
D I M E N S I O N S
Total height
Total width
Total depth
Center distance, flow/return
Pipe connections
Connection for expansion vessel
Outlet of pressure relief valve
O P E R A T I N G D A T A
Max. admissible pressure
Max. operating temperature
Max. propylene glycol content
Operating temperature storage tank and
collector sensors
E Q U I P M E N T
Pressure relief valve
Pressure gauge
Flow rate display
Sensors
Check valves
(integrated in the ball valves)
M A T E R I A L S
Valves and fittings
Gaskets
Check valves
Insulation
795 mm
688 mm
298 mm
120 mm
¾" internal thread
¾" external thread, flat sealing
¾" internal thread
prim. / sec.: 6 bars
prim.: 120 °C / sec.: 95 °C
50 %
-50 °C to +180 °C
prim. / sec.: 6 bars
0-6 bars
prim. / sec.: 3-22 l/min
1 x Pt1000 (integrated), 3 x Pt1000 (enclosed)
prim. 2 x 19.6 mbars, can be opened
sec.: 1 x 19.6 mbars, can be opened
Brass
Klingersil / EPDM
Brass
EPP , l = 0.041 W/(m K)
5 3
