Use - Tylo CROWN COMBI ELITE Benutzerhandbuch

8
WARNING!
• The sauna room or cabin is to be inspected before
either restarting the timer or by switching on the app-
liance by a separate remote-control system
• The sauna room or cabin is to be inspected before
setting the appliance to a standby mode for a delayed
start
• The door of the sauna room or cabin is fitted with an
interlock such that the stand-by mode setting for re-
mote operation is disabled if the sauna door or cabin
door is opened when the stand-by mode setting for
remote operation is set

USE

The control panel in general
See instructions supplied with the control panel.
Water reservoir
The sauna heater works with and without water in the tank.
When the water reservoir is in use, max. two out of three heating
elements in the stone compartment will be working. The heater
switches automatically between the reservoir and stone compart-
ment, depending on which setting/prioritisation has been set on
the control panel. See the instructions supplied with the control
panel.
Filling the water reservoir:
Before starting the heater, fill the water reservoir by carefully
pouring tap water through the herb grille, see fig. 3.
Figure 3: Filling the water reservoir.
NB! Never use salt water - can damage the heater
element in the reservoir. It can also cause a build
up of foam which causes the level sensor to detect
a higher water level than actual, and the heater ele-
ments can break.
When filling without the herb grille, you risk overfil-
ling the tank due the electronics response time.
1. An empty reservoir is shown by two empty drop symbols on the
Elite control panel display. If the reservoir is empty when activa-
ting the main switch, three pulsing audio signals will sound
2. When the water level reaches the level sensor (Mid), a filled
drop symbols will be shown on the Elite control panel display
(Pure control panel shows an unlit drop symbol). The heater ele-
ment in the reservoir can be started.
3. When the water level reaches the upper level sensor, two
filled-in drop symbols will show on the Elite control panel display
A continuous audio signal will also sound for approx.: 2 secs,
indicating that the water level in the tank is full (in case you do not
check the control panel display during filling).
NB! Do not add more water after the audio signal to
avoid the water boiling over and out of the reservoir.
Water reservoir in operation:
1. When in use and if the water level drops below the upper level
sensor, it will continue to operate as normal but a single filled-in
drop symbol will show on the Elite control panel display. Water
can be added, and a steady audio signal will sound when the
water level reaches full.
2. When in use and if the water level drops below the level sensor
(Mid), three pulsing audio signals will sound and two empty drop
symbols will show on the Elite control panel display. This indica-
tes that there is insufficient water in the reservoir, and the heater
element will automatically switch off.
Other functions
Fragrance holder
DANGER! Never put fragrances in the herb bowl
or water reservoir.
DANGER! Fragrant essences etc. may ignite if
poured directly onto the stones.
To create a pleasant fragrance in the sauna, pour a few drops
of of the Tylö sauna fragrance into the water in a sauna bucket
and pour the water on fully heated stones. Use a sauna ladle
for pouring water slowly on the hot stones. Don't pour too much
water, the water must have time to evaporate. If too much water is
poured, water will go trough the heater and down on the floor.
Tylö Sauna Fragrance comes in different variants and fragrances.
Go to www.tylo.com to see the full range.
1
Figure 4: Other functions
1. Herb bowl
Herb bowl
A fragrant, refreshing herbal sauna can be created with fresh
or dried herbs or spices. Enjoy pleasant herbal fragrances in a
steamy tropical climate.
To create a fragrant sauna using fresh or dried herbs, put the
herbs in the herb bowl (see Figure 4).
TIP! Try different combinations, such as birch,
lavender, mint, spices, tea bags and other exciting
fragrances.
