5.2.

SPEED MEASUREMENT WITH CONTACT (RPM)

1. Fit the the mechanical adapter (see Fig. 1 – part 1) onto the instrument and use the
extension sleeve, if necessary (see Fig. 1 – part 2).
2. Insert the proper rubber head onto the mechanical adapter.
3. Turn on the instrument by pressing the
4. Press the MODE key and select "rPM, HZ, M/M, I/M, F/M or Y/M" modes on the display
(see § 4.2.2)
5. Press and hold the
object to be measured (see Fig. 3) and perform the measurement. The "
always shown at display during measurements.
6. Release the
automatically displayed to freeze the value.
7. Press the MEM key to save the measured result (see § 4.2.3).
Fig. 3: Speed measurement with contact
/MEAS key, pushing the rubber head against the shaft of the
/MEAS key to stop any measurement. The "HOLD" symbol is
/MEAS key.
EN - 7
HT2236
" symbol is
