MIG SERIES EQUIPMENT
Summary
Description
Weight
Dimensions
Cooling
Welder Type
European Standards
Number of Phases
Nominal Supply Voltage
Nominal Supply Frequency
Output Voltage Range
Wirefeeder Speed Range
Wire roll weight
Wire roll diameter
Thickness of material
Efficiency
Power Factor
Welding Current Range (MIG Mode)
Welding Current Range (MMA Mode)
Welding Current Range (TIG Mode)
Effective Input Current
Maximum Input Current
Single Phase Generator Requirement
Duty cycle, 40°C, 10 min(MIG)
Duty cycle, 40°C, 10 min(MMA)
Duty cycle, 40°C, 10 min(TIG)
Open Circuit Voltage
Protection Class
Insulation Class
Gas Follow
NOTE
Note 1: The Effective Input Current should be used for the determination of cable size & supply
requirements.
Note 2: Generator Requirements at the Maximum Output Duty Cycle.
Note 3: Motor start fuses or thermal circuit breakers are recommended for this application. Check local
requirements for your situation in this regard.
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings, all
capacities, measurements, dimensions and weights quoted are approximate only. Achievable capacities
and ratings in use and operation will depend upon correct installation, use, applications, maintenance
and service.
53
VECTOR DIGITALF MIG255
11.5kg
H493mmxB222mmxT375mm
Fan Cooled
Multi Process Inverter Power Source
EN 60974-1 / IEC 60974-1
1
230V +/- 15%
50/60Hz
10-25 V
2.5-15
15kg
0.6/0.8/1.0
Up to 0.8mm
80%
0.8
30-255 A
30-170 A
10-200 A
30 A
50.7A
15KVA
255A@ 35%26.7V 151A@ 100%21.6V
170A@ 35%26.8V 100A@ 100%24V
200A@ 35%18V 118A@ 100%14.7V
60V DC
IP23
F
3s
MIG SERIES EQUIPMENT
Description
Weight
Dimensions
Cooling
Welder Type
European Standards
Number of Phases
Nominal Supply Voltage
Nominal Supply Frequency
Output Voltage Range
Wirefeeder Speed Range
Wire roll weight
Wire roll diameter
Thickness of material
Efficiency
Power Factor
Welding Current Range (MIG Mode)
Welding Current Range (MMA Mode)
Welding Current Range (TIG Mode)
Effective Input Current
Maximum Input Current
Single Phase Generator Requirement
Duty cycle, 40°C, 10 min(MIG)
Duty cycle, 40°C, 10 min(MMA)
Duty cycle, 40°C, 10 min(TIG)
Open Circuit Voltage
Protection Class
Insulation Class
Gas Follow
NOTE
Note 1: The Effective Input Current should be used for the determination of cable size & supply
requirements.
Note 2: Generator Requirements at the Maximum Output Duty Cycle.
Note 3: Motor start fuses or thermal circuit breakers are recommended for this application. Check local
requirements for your situation in this regard.
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings, all
capacities, measurements, dimensions and weights quoted are approximate only. Achievable capacities
and ratings in use and operation will depend upon correct installation, use, applications, maintenance
and service.
Summary
VECTOR DIGITALF MIG295
13kg
H493mmxB222mmxT375mm
Fan Cooled
Multi Process Inverter Power Source
EN 60974-1 / IEC 60974-1
3
400V +/- 15%
50/60Hz
10-25 V
2.5-15
15kg
0.6/0.8/1.0
Up to 0.8mm
80%
0.8
30-295 A
30-250 A
10-280 A
11 A
24.8A
15KVA
295A@ 60%28.8V 228A@ 100%25.4V
250A@ 60%30V 194A@ 100%27.8V
280A@ 60%21.2V 217A@ 100%18.7V
60V DC
IP23
F
3s
