Model assembly

Landing gear set installation
1.With the fuselage bottom facing up, carefully Install the landing
gear set to the fuselage with the included screws as shown.
Main wing set installation
1.Have the screws go through the supporting bar and then secure on the base.
2.Lock up the fasteners of supporting bar on fuselage as shown.
3.Slide the tube into the fuselage then install both wings over the
wing tube and into the wing slot of the fuselage.
Notice: The connectors on both side should be attached
precisely and firmly.
PA2.6*15
PA2.6*15
KA2.0*8
4
