Model assembly

Main wing installation
1.Slide the tube into the fuselage then install both wings over the
wing tube and into the wing slot of the fuselage.
Note: The connectors on both sides should be attached precisely
and firmly.
2.Secure the both wings into the fuselage using the included 4
screws.
Horizontal stabilizer installation
1.Connect the elevator servo connectors to the servo exten-
sions in the fuselage.
2.Slide the horizontal tail in the rear of the fuselage. Ensure the
control horn faces down as shown.
HKM3.0*16 Black
4
