Model assembly

Landing gear installation

1. With the fuselage inverted, fit the landing gear assembly into its
corresponding slot as shown.
2. Use the included screws to secure the landing gear plate and
landing gear to the fuselage.
Horizontal stabilizer installation
1. Insert the horizontal stabilizer into the slot aft of the fuselage,
secure the assembly with screws.
HKM3.0*10
4
HKM3.0*16
HKM3.0*16
