System fault no.:
2 2 2 2 4 4
A full list of system faults can be found in the PILOT BOX Installation Guide.

Technical Data

Nominal Voltage:
Operating Temperature:
Mode of Protection:
Dimensions:
TECHNICAL DATA
Possible cause / Remedy:
RUDDER DRIVE FAULT
The Pilot computer has sent a drive command to the drive unit but the Rudder
Feedback Unit has not detected a change in the rudder position.
Check that the Rudder Feedback has not become disconnected from the
Rudder Arm, also check that the steering system, especially the motor, is ope-
rating the rudder gear correctly.
Ensure that the drive unit cables have not become disconnected or loose.
12 / 24 VDC
0° bis +55 °C
DIN 40050-IP65
220 mm x 75 mm (max.)
further dimensions on page xx
EMC Directive 89/336/EEC
This product has been designed to be compliant with the above Directive.
Maximum performance and compliance with the EMC Directive can only be
ensured by correct installation.
